Project 4: The Warhol Project
The purpose of this project is to make a collection of images in the style of Andy Warhol. You'll do this by manipulating the pixel colors of an image.
Here is the reference guide to the graphics package.
Make sure you have copies of the graphics.py and display.py files.
For this assignment you're going to create two python programs. One will generate a Warhol style collage. The other will change the blue screen to a different color. Both will write their results to an image file, which you can then view with your show program.
In your filter.py file, create a function placeImage which
takes four arguments. The first argument will be a destination
Image, the second argument will be a source Image, and the last two
arguments will be an x, y location to place the second Image into the
first. The function outline in comments is given below.
For each comment inside the function below, you need to write one line of python code.
# place src into dst with upper left at x, y in dst def placeImage( dst, src, x, y ): # assign to rows the height of the src image # assign to cols the width of the src image # loop over each row i in src # loop over each column j in src # assign to the tuple (r, g, b) the result of calling getPixel on src with arguments (j, i) # using dst, call the setPixel method to set location (x + j, y + i) to the color (r, g, b)
The setPixel function expects a Zelle color. You can create a Zelle color using the function graphics.color_rgb(r, g, b). The color_rgb function expects values between 0 and 255 for each color channel.
Once you have written your function, you can use this file to test it. Run the test program on the command line and give it an image filename as its argument. For example:
python testPlaceImage.py miller.ppm
If you look at the end of test program, you will see that it writes the output to a file called duplicate.ppm. You can use your show.py program to view the duplicate.ppm image. It should show two copies of the original image, side-by-side.
As you are working with your code, remember that the Zelle graphics package can read only PPM type images.
Once you are confident that your placeImage function works, please remove the comments that we supplied. They don't help the reader understand the overall purpose of the code because they are a line-by-line annotation of what each line does. In most cases, that is obvious from the code itself. Helpful comments include the docstring (which you need to write), which explains the meaning of each parameter.
- Create three more functions like swapRedBlue that edit the colors in a Image to achieve some effect. See if you can emulate some of the Instagram effects. Note: when we say "like swapRedBlue", we do not mean "variants of swapRedBlue". A filter that simply reorders the color channels will not count towards your three (though you are welcome to write them in addition to your three, if you like the effect).
Your main warhol program (which you should put in a file named
warhol.py) should read in one image, create four copies of it, use
your filter functions to alter tham, create a new blank image that is
width*2 by height*2 and then use the placeImage function to insert
the four edited images. Finally, it should write out the collage
image. The code below is a skeleton of the algorithm.
def main(argv): # if the length of argv is less than 2 # print a usage statement # exit # assign to a variable (e.g. img) the result of reading in the Image from argv # clone img and assign it to a new variable (e.g. map1) # clone img and assign it to a new variable (e.g. map2) # clone img and assign it to a new variable (e.g. map3) # clone img and assign it to a new variable (e.g. map4) # call your first manipulator function on map1 # call your second manipulator function on map2 # call your third manipulator function on map3 # call your fourth manipulator function on map4 # create a new Image that is 2*width x 2*height and store it in a new variable (e.g. collage) # put map1 into the collage at (x, y) = (0, 0) # put map2 into the collage at (0, height) # put map3 into the collage at (width, 0) # put map4 into the collage at (width, height) # save the big image (e.g. collage) to a file
Finish up this task by putting a call to main inside the conditional statement we've used before. Then call your python program and view the collage.
Tip: For this function, helpful comments would indicate the different sections of code (e.g. "read in one image", "make 4 copies of it", "make an empty image big enough to hold 4 copies of this one", and "put the 4 filtered images into the big one"). And, of course, a docstring is a must.
Your last task is to create a python program that reads in your
blue/green-screen image and turns the background pixels to a different
color. You can find your image here. The rest of the pixels should remain untouched. You will need
to loop over each pixel in the image and test if it is very blue/very
green. If it is very blue/very green, change its color. Otherwise,
leave it alone.
A reasonable test for 'very blue' is if the blue channel is 1.5 times the red channel and also bigger than the green channel. You can do something similar to define 'very green'.
- Create a larger or more complex Warhol style collage. Place the images in a pattern more complicated than that of a square (but not random!).
- Do something more interesting than a single color to replace the blue screen.
- Place yourself in a scene. Start with a background scene that is the same size image as your blue-screen image. Then copy only non-blue pixels from your images into the background. You can do this by making a version of placeImage that copies only non-blue pixels. You could call it placeImageWithoutBlue.
- Enable your Warhol program to read in multiple images from the command line and make a collage for each one, or a collage that integrates several images.
- Make a function or functions that modify the image based on one or more parameters and demonstrate that you can make several different output images by varying the parameter.
Make a new wiki page for your assignment. Put the label cs151f17project4 on the page. Each of you needs to make your own writeup.
In addition to making the wiki page writeup, put the python files you wrote on the Courses server in your private directory in a folder named Project4.
In general, your writeup should follow the outline below.
A brief summary of the task, in your own words. This
should be no more than a few sentences. Give the reader (a
peer not in the course) context and identify the key
purpose of the assignment. You can assume your reader has
read through your prior assignments.
Writing an effective summary, or abstract, is an important skill. When you are writing yours, consider the following questions.
- Does it describe the CS purpose of the project (e.g. writing well-organized and efficient code)?
- Does it describe the specific project application (e.g. making pictures of space stuff)?
- Does it describe your the solution or how it was developed (e.g. what were you trying to draw and how)?
- Does it describe the results or outputs (e.g. did it turn out reasonably well)?
- Is it concise?
- Are all of the terms well-defined?
- Does it read logically and in the proper order?
- A description of your solution to the tasks, including any images you created. This should be a description of the form and functionality of your final code. You may want to incorporate very short code snippets in your description to point out relevant features. Note any unique computational solutions you developed. Code snippets should be small segments of code--usually one or two lines and normally much less than a whole function--that demonstrate a particular concept. If you find yourself including more than 5-10 lines of code, it's probably not a snippet.
- A description of any extensions you undertook, including images demonstrating those extensions. If you added any modules, functions, or other design components, note their structure and the algorithms you used.
- A brief description (1-3 sentences) of what you learned. Think about the answer to this question in terms of the stated purpose of the project. What are some specific things you had to learn or discover in order to complete the project?
- A list of people you worked with, including TAs, and professors. Include in that list anyone whose code you may have seen, such as those of friends who have taken the course in a previous semester.
- Don't forget to label your writeup so that it is easy for others to find. For this project, use cs151f17project4
