Due: , 11:59 pm

Objectives

The project this week is to continue to make shape classes, making use of inheritance, starting with a tree class.

Tasks

  1. The first task is to make a Tree shape class, similar to the Square and Triangle classes. The difference between a Tree and a Square, though, is that the Tree generates its string dynamically using an L-system. The string for a Square is always the same, so it can set the string field once and then use the parent Shape class' draw method. However, every time we draw a tree, we first must build a string using an L-system. Then it can use the Shape draw method.

    Because we use an L-system to generate the string to draw, a Tree object must contain an L-system, which means it must have a field that holds an L-system object.

    Because a Tree is a Shape, it must be a child of the Shape class. That lets it use the parent methods for setting color, distance, and angle, among other things.

    To make our Tree class, start by creating a file called tree.py. Import your lsystem and shape modules. The Tree class should be derived from the Shape class, but you'll need to override some of the methods because of the special nature of a Tree: it needs more fields than a simple Shape, and it has to dynamically create the string it will draw using an L-system.

    The methods you'll need to override or create for the Tree class include:

    • def __init__(self, distance=5, angle=22.5, color=(0.5, 0.4, 0.3), iterations=3, filename=None): - The init method should call the parent (Shape) init method with self, distance, angle, and color, store the iterations number in an iterations field, then create an Lsystem object (passing in the filename) and store it in an lsystem field.
    • Create a setIterations(self, iterations) accessor method for the iterations field of the Tree object.
    • Create a read(self, filename) method that calls the lsystem object's read method with the specified filename. Use the Lsystem object you created and stored in the lsystem field to call the read method.
    • Override the draw method--but keep the same parameter list--so it uses the Lsystem to build the string, assigns the string to the string field of self, and then calls the parent draw method. You may want to change the default orientation for this function to 90 so the trees grow up.

    Once you've written the tree class, make a test method for the class and try it out. The test method should take in an Lsystem filename, create a Tree object, and then use the Tree object's draw method to draw at least 3 trees. Use an L-system with multiple replacements for at least one rule (e.g. systemJ.txt and show the three trees are different.

    The output of your tree.py test method is required image 1.

  2. In shapes.py, create at least three classes--other than Square and Triangle--that are derived from the Shape class and define different shapes using strings. One of them should make a filled shape using curly brackets { and } to turn on and off the fill. Make a test function for your shapes.py file that generates an image that incorporates all of the shapes you created. The function should test all of the capabilities of the different shape classes.

    The output of your shapes.py test method is required image 2.

  3. In a file named colby.py, Create a new scene representing somewhere on campus. Give your scene a title in your report. Use your various shape classes and include at least one tree in the scene. Use only the Tree and shape classes from this assignment to create the scene, not your turtle code from prior assignments. Only the TurtleInterpreter class should execute turtle commands.

    The Colby scene is required image 3.

  4. In a file named mosaic.py, create a function tile(x, y, scale) that draws a set of shapes inside a square that is scale by scale in size with the lower left corner of the tile at location (x, y). If scale is 10, then the tile should be 10x10.

    Then make a function mosaic(x, y, scale, Nx, Ny) that draws a 2D array of tiles Nx by Ny, where each tile is of size scale by scale, and the lower left corner of the mosaic is at (x, y). So if scale is 10, Nx is 3 and Ny is 4, the function should draw twelve 10x10 tiles three across and four down.

    An image of at least 20 tiles (5 x 4) in a non-square arrangement is required image 4.

Example Extensions

These are just examples. Please get creative. It can make a big difference when you pursue an extension that genuinely interests you!

Writeup

Make a new wiki page for your assignment. Put the label cs151s18project9 on the page. Each of you needs to make your own writeup.

In addition to making the wiki page writeup, put the python files you wrote on the Courses server in your private directory in a folder named project9.

Colby Wiki

In general, your writeup should follow the outline below.
